GX50 Petrol-Powered Portable Winch
Features the GX50 engine by Honda, an all-position engine. This winch also stands out by providing perfect control over the movement of a load with the Progressive Capture System (PCS).
High-Grade.
Launched in 2020, designed after having listened to our wincher’s community to fulfill another need.
The PCW4000 features a centrifugal clutch that activates when you pull the rope. The more you pull, the more throttle you give. When the tension on the rope is released, the drum stops spinning and the Progressive Capture System (PCS) holds the load flawlessly in position! A simple lateral movement is all it takes to disengage the rope. Easy to secure and easy to disengage!
This model is powered by the 360° inclinable 4-stroke Honda GX50 engine for smooth performance and reliability, offering a remarkable pulling force of 1,000 kg (2,200 lb). Add a pulley system of two double pulleys; you can pull up to five times (5x) the pulling capacity, for a total of 5,000 kg (11,000 lb)!
And like all our portable capstan winches, there is no limit to the pulling distance thanks to the capstan principle.
- Unleaded gasoline, 86 octane or higher
- Centrifugal clutch
- Drum size: 76 mm
*Note: the PCS cannot be installed on other pulling winches mainly because the other models don't have a centrifugal clutch and that the PCS acts as the throttle on the PCW4000, which cannot be replicated on direct shafted winches.
* Click on the "Download" tab to get the detailed product specifications, user manual and more.
- PCW4000
- Rope bag to store and carry your rope
- 50 m (164 ft) rope for smooth pulling operations
- RopeWizerTM - The Easy Splice to retain nearly 100% of the capacity of your rope and easily attach the carabiner
- Single pulley to either deviate the pull angle or double the power of the winch
- Steel locking carabiners 2x; one to link the pulley to the sling and one for the end of your rope
- Safety Hook with Latch to place at the end of the rope to easily attach to the load
- 2 m (6 ½ ft) Polyester sling to attach the pulley to a tree for example
- 2.5 m (8 ¼ ft) round polyester sling to anchor the winch wherever you need it!
- PCW4000
- 2.5 m (8 ¼ ft) round polyester sling to anchor the winch wherever you need it!
- Technical Data Sheet
- Spare Parts
- User Guide
- Honda engine GX35 and GX50 manual
- How to Double the power, with block-and-tackle
- The PCW4000 benefits from its own dedicated website!
Go check it!
Complete your selection
Customer Reviews
Based on 55 reviews
91%
(50)
5%
(3)
2%
(1)
0%
(0)
2%
(1)
R
This winch has been one of our best purchases for starting our homestead. Able to set up anywhere you can walk and get logs to a skid trail. Helped taking down hung up trees, pulling out 5th wheel trailer up a muddy hill. With the nose cone logs don't get hung up. Using pulleys we were able to move far bigger logs than I would have thought possible. Recommend using the higher rated pulleys and carabiners if testing how much the winch can pull.
I did have to replace the original plastics PCS with the upgraded metal one as I wasn't paying close enough attention and allowed a tangled rope to break it. With the amount of use we have gotten and looking forward to many more years.
J
c'est une machine qui va très très bien .................peut être juste le cône qui ce déplace beaucoup et des fois il débarque ............
M
Bought this winch for a moose hunt. I wanted a winch that was safe, keeping body parts out of the process and line of fire, and efficient where it does all the work instead of me. I haven’t used it on the moose hunt yet but I have used it to pull a stuck 3/4 ton pick up out of the mud while on a scouting trip in northern Maine. I used two snatch blocks for a three to one advantage. Pulled the truck out with little effort. THANKS PORTABLE WINCH FOR AN AWESOME PRODUCT.
R
I have used this winch to pull 12 to 16 inch ash trees that were hung up in adjacent trees. I purchased two additional double pulleys to increase the winch strength. The winch had enough pulling force to lift one of the trees off the ground, on the angle, before pulling it out of the adjacent tree. Portable winch has YouTube videos that show an example of a block and tackle system to increase the force of the winch. Very satisfied.
R
I have used this winch to pull 12 to 16 inch ash trees that were hung up in adjacent trees. I purchased two additional double pulleys to increase the winch strength. The winch had enough pulling force to lift one of the trees off the ground, on the angle, before pulling it out of the adjacent tree. Portable winch has YouTube videos that show an example of a block and tackle system to increase the force of the winch. Very satisfied.
Hi Mr. Rhodes
Thank you for taking the time to leave a review! We are thrilled to hear that it was able to help you with pulling hung up ash trees and happy to hear that you were able to utilize the winch's strength. Thank you for mentioning our helpful YouTube videos as well. We love hearing about happy and satisfied customer like you.
Best regards,
The Portable Winch Co. Team
